HP NX9500 Table, 135W AC Adapter (PFC)

Specifications

Table 6-8

135W AC Adapter (PFC)

Dimensions
Height	16.9 cm	6.65 in
Width	6.5 cm	2.56 in
Depth	3.8 cm	1.50 in
Weight	700 g	1.54 lb
Input
Operating voltage	100 to 240 V ac
AC current	2.2 A at 90 V ac,
	1.1 A at 180 V ac
Frequency range	47 to 63 Hz
Efficiency	83% min at
	115 V ac
Input efficiency	Input frequency
	range
Output
Output power	135 W
DC output	19.0 V
Hold-up time	5 msec at 115 V ac input
Output current limit	< 9.5A, Over voltage protection
	- 29V max automatic shutdown
Connector	3 pin/grounded, mates with
	interchangeable boards
Environmental design
Operating temperature	0°C to 35°C	32°F to 95°F
Non-operating temperature
(storage)	-20°C to 65°C	-4°F to 149°F
Altitude	0 to 3,048 m	0 to 10,000 ft
Humidity	20% to 80%
Storage humidity	10% to 90%

Maintenance and Service Guide 6–9
