Removal and Replacement Procedures

5.11 Top Cover

Spare Part Number Information

Top cover



For use with HP zd7000 models

344876-001

For use with HP Compaq nx9500 models

370803-001





1.Prepare the notebook for disassembly (Section 5.3) and remove the following components:

Optical drive (Section 5.7)

Keyboard (Section 5.8)

Keyboard cover (Section 5.9)

Display assembly (Section 5.10)

2.Turn the notebook upside down with the front toward you.

5–26

Maintenance and Service Guide
