Removal and Replacement Procedures

5.12 System Board

Spare Part Number Information

For use with HP zd7000 models NVIDIA GeForce FX Go5600 Ultra with 64-MB video memory NVIDIA GeForce FX Go5600 Ultra with 128-MB video memory NVIDIA GeForce FX Go5200 Ultra with 64-MB video memory NVIDIA GeForce FX Go5200 Ultra with 128-MB video memory

NVIDIA GeForce FX Go5700 with 64-MB video memory NVIDIA GeForce FX Go5700 with 128-MB video memory

For use with HP Media Center zd7000 and HP Compaq nx9500 models

NVIDIA GeForce FX Go5700 with 64-MB video memory NVIDIA GeForce FX Go5700 with 128-MB video memory

356668-001

356669-001

356670-001

365892-001

365893-001

365894-001

365893-001

365894-001

When replacing the system board, ensure that the following components are removed from the defective system board and installed on the replacement system board:

Memory modules (Section 5.5)

Mini PCI communications board (Section 5.6)

Real time clock battery (Section 5.13)

Heat sink (Section 5.14)

Processor (Section 5.15)

5–30

Maintenance and Service Guide
