Single ARM | Lincoln Electric IM986 specs

POWER WAVE® i400

Electrode

Connection

AutoDrive 4R90

K2685-2

Wire Feeder

Gas

Air

ARC Mate 1XXiC

* Electrode

Cable (+)

K2163-xx or

K1842-xx

Optional Work

Sense Lead (21)

FANUC Robotics R-30iA "a-cabinet" Controller with Integrated Op Box

ArcLink XT

Ethernet Cable

Power Wave i400

K2669-2

Circuit Breaker (15 Amp)

Devicenet

Connector

Wire Feeder Connector

Voltage Sense

Connector

TYPICAL STAND ALONE SYSTEMS

A-9

INSTALLATION

Wire Feeder Control cable K1785-xx

Work

Piece

* Work

Cable (-)

K2163-xx or

K1842-xx

ArcLink

Connector

ArcLink XT Ethernet Connector

(SINGLE ARM)

OR

* Refer to Output Cable guidelines for recommended cable size in PowerWave i400 Instruction Manual.

A-9

Image 18

Lincoln Electric IM986 manual Single ARM
