Configuration with Advanced Setup

Transmission mode

The transmission mode indicates whether the wireless transmission complies with IEEE Standard 802.11b or IEEE 802.11g, or whether both transmission modes are possible (Mixed mode). The main difference between the two standards is the Transmission rate: IEEE 802.11b – maximum 11 Mbps, IEEE 802.11g – maximum 54 Mbps. If the units use different standards in the wireless network, then you should leave the default Mixed mode.

Transmission rate

The transmission rate depends on the selected transmission mode. The possible transmission rates are shown in the pick list. You should leave the default set to Auto.

Click on APPLY to apply the settings.

Setting the Encryption

If you are sending sensitive data over wireless channels, we recommend that you activate WEP-Encryptionon your wireless network components.

i

Wired Equivalent Privacy (WEP) protects data transmitted between wireless nodes. However WEP does not protect transmission on your wired network or over the Internet.

To activate WEP encryption on your wireless network components:

1.Activate Web encryption on your Gigaset SE505 dsl/cable and generate a 64 or 128 bit key. Make a note of the generated key.

2.Activate WEP encryption on the wireless network adapters and enter the generated 64 or 128 bit key.

You can choose either the standard 64 bit key or the more robust 128 bit key for encryption. The keys are generated in hexadecimal format. You must use the same keys for encryption and decryption for the Gigaset Router and all your wireless network adapters.

i

You will find a detailed example of how to set up WEP encryption in "Practical Tips and Configuration Examples" on the CD supplied.

71
