10Enter the correct time and date in the System Setup program's Time and Date fields.

11Exit the System Setup program.

Control Panel Assembly

Removing the Control Panel Assembly

CAUTION: Many repairs may only be done by a certified service technician. You should only perform troubleshooting and simple repairs as authorized in your product documentation, or as directed by the online or telephone service and support team. Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

1If installed, remove the front bezel. See "Removing the Front Bezel" on page 61.

2Turn off the system and attached peripherals, and disconnect the system from the electrical outlet and peripherals.

3Open the system. See "Opening the System" on page 62.

4Remove hard drive 0. See "Removing a Hard Drive" on page 67.

5Disconnect the control panel cable at back of the control panel board:

CAUTION: Do not pull on the cable to unseat the connector. Doing so can damage the cable.

aPress the metal tabs on the ends of the cable connector.

bGently work the connector out of the socket.

cRemove the USB connector cable from the control panel.

6Remove the four screws that secure the control panel board to the chassis and remove the board.

Installing System Components

101
