Icom IC-R3 instruction manual Italian channels, FOT channels, Tv Frequency Table

TV FREQUENCY TABLE 16

			■ Italian channels									■ FOT channels
CH	Video	Audio	CH	Video	Audio	CH	Video	Audio	CH	Video	Audio	CH	Video	Audio
64	815.25	820.75	A*	53.75	59.25	38	607.25	612.75	65	823.25	828.75	4	175.25	181.75
65	823.25	828.75	B*	62.25	67.75	39	615.25	620.75	66	831.25	836.75	5	183.25	189.75
66	831.25	836.75	C*	82.25	87.75	40	623.25	628.75	67	839.25	844.75	6	191.25	197.75
67	839.25	844.75	D*	175.25	180.75	41	631.25	636.75	68	847.25	852.75	7	199.25	205.75
68	847.25	852.75	E*	183.25	188.75	42	639.25	644.75	69	855.25	860.75	8	207.25	213.75
69	855.25	860.75	F*	192.25	197.75	43	647.25	652.75				9	215.25	221.75
			G*	201.25	206.75	44	655.25	660.75
			H*	210.25	215.75	45	663.25	668.75
			H1*	217.25	222.75	46	671.25	676.75
			H2*	224.25	229.75	47	679.25	684.75
			21	471.25	476.75	48	687.25	692.75
			22	479.25	484.75	49	695.25	700.75
			23	487.25	492.75	50	703.25	708.75
			24	495.25	500.75	51	711.25	716.75
			25	503.25	508.75	52	719.25	724.75
			26	511.25	516.75	53	727.25	732.75
			27	519.25	524.75	54	735.25	740.75
			28	527.25	532.75	55	743.25	748.75
			29	535.25	540.75	56	751.25	756.75
			30	543.25	548.75	57	759.25	764.75
			31	551.25	556.75	58	767.25	772.75
			32	559.25	564.75	59	775.25	780.75	NOTE:
			33	567.25	572.75	60	783.25	788.75
									*In the case of the IC-R3,
			34	575.25	580.75	61	791.25	796.75
									‘A’–‘H,’ ‘H1’		and ‘H2’
			35	583.25	588.75	62	799.25	804.75
									channels are displayed
			36	591.25	596.75	63	807.25	812.75
									as ‘1’–‘8,’ ‘9’ and ‘10,’ re-
			37	599.25	604.75	64	815.25	820.75
									spectively.

53
