Ricoh 70E - page 53

Preparation for Installation 4-5

II L 00

[Finisher SR5000] with Transit Pass Unit Type DDP

7) Install the SB Cover Paper Guide to the Printer.

SB Cover Paper Guide

M3x6 Screw
