CHECK

Open and close the SB Cover.

When the SB cover does not open, adjust Transit Pass Unit Type DDP to an arrow direction.

Lower Paper Guide

SB Cover

Adjust arrow direction

Transit Pass Unit Type DDP

(2)Install the Transit Pass Unit Type DDP by using the four M4x8 Screws.

(3)Close the Lower paper guide and Front Cover.

CHECK

Open and close the Lower paper guide. When Lower Paper Guide and SB Cover Paper Guide collide, repair it by hand because SB Cover Paper Guide may transform it.

Lower Paper Guide

Upper Paper Guide

Lower Paper Guide

SB Cover Paper Guide

SB Cover Paper Guide
