Ricoh 70E installation manual Adjustment of paper feeding position of Tray

5.5 Adjustment of paper feeding position of Tray 1

When Container Stacker 1 or Container Stacker 2 was installed. This adjustment is applied to DDP70 and DDP92.

When container stacker 1 and container stacker 2 are installed, confirm paper feeding position in container stacker 2.

1)Print the same sized paper from tray 1 and tray 2, and check the paper feeding position.

2)In case that the configuration includes Container Stacker 1, check the paper feeding position on the sample tray.

3)In case that the configuration includes Container Stacker 2, open the Top Cover of the Container Stacker 2 , insert the cheater in the interlock switch, and check the paper feeding position on the slit between paper guides.

-The cheater is in the accessory box of the printer.

4)Set a standard point in the sample tray and the frame of Container Stacker and check the gap of the paper feeding position between tray 1 and tray 2, whether the paper is closer to the front side or the rear side.

5)When the paper from Hopper 1 is closer to the front side compared with the paper from Hopper 2, there is no need to add Hopper Spacer.

6)When the paper from tray 1 is closer to the rear side by 1-2mm compared with the paper from tray 2, add 1 piece of Hopper Spacer at each location as shown in the following figure.

7)When the paper from tray 1 is closer to the rear side by 2mm or more compared with the paper from tray 2, add 2 pieces of Hopper Spacer at each location as shown in the following figure.

II

L00 Installation 5-6
