3745 Panel Codes

Table 1-5 (Page 16 of 33). Panel Codes. An

ñ
following a panel code denotes that the code should 'Blink'.
Panel
Code Definition Action: Go to “3745 FRU Group
Table” on page 1-49
or to MAP number
A9DñMoss level 0 error detection; DFA; CHIO; No CHIO in
progress in Adapter Control Block If loading from diskette (function 9
from the control panel) then exchange
the FRU group 45; if loading from
HDD then exchange the FRU group
46
A9EñMoss level 0 error detection; DFA; PIO; Bus check;
Inbound parity
A9FñMoss level 0 error detection; DFA; PIO; Bus check;
Adapter failure
AA0ñMoss level 0 error detection; DFA; PIO; Bus check;
Adapter not detected
AA1ñMoss level 0 error detection; DFA; PIO; time out; Invalid
command If loading from diskette (function 9
from the control panel) then exchange
the FRU group 45; if loading from
HDD then exchange the FRU group
46
AA2ñMoss level 0 error detection; DFA; PIO; time out; Out-
bound address parity check
AA3ñMoss level 0 error detection; DFA; PIO; time out; Out-
bound command/data parity check
AA4ñMoss level 0 error detection; DFA; PIO; time out;
Adapter failure
AA5ñMoss level 0 error detection; DFA; PIO; time out; Mul-
tiple bits detected in Stat reg
If loading from diskette (function 9
from the control panel) then exchange
the FRU group 45; if loading from
HDD then exchange the FRU group
46
AA6ñMoss level 0 error detection; TOD; Adapter is 'down'
Exchange the FRU group 2
AA7ñMoss level 0 error detection; TOD; PIO; Bus check;
Inbound parity
AA8ñMoss level 0 error detection; TOD; PIO; Bus check;
Adapter not detected
AA9ñMoss level 0 error detection; TOD; PIO; time out; Out-
bound address parity check
AAAñMoss level 0 error detection; TOD; PIO; time out; Out-
bound command/data parity check Exchange the FRU group 2
AABñMoss level 0 error detection; PLC; Adapter is 'down' Exchange the FRU group 12
AAC to
AAD Unused Go to “MAP 3220: Undefined Panel
Message” on page 2-5
AAEñMoss level 0 error detection; PLC; MMIO Interface error
OR Invalid address during main store data access ( ON
level 2)
exchange the FRU group 12. Record
the following action for use if the
problem is not corrected by the FRU
exchange; A MOSS microcode
problem is suspected. Call your
support structure, refer to “Contacting
Support” on page A-1.
AAFñMoss level 0 error detection; PLC; MMIO Parity error
OR Memory storage; Storage ECC; Data parity ( ON
level 2) Exchange the FRU group 12
AB0 Unused Go to “MAP 3220: Undefined Panel
Message” on page 2-5
AB1ñMoss level 0 error detection; UC Bus; Bus is 'down' Exchange the FRU group 1
AB2ñMoss level 0 error detection; Register Storage; PIO
Storage ECC; Data parity whilst accessing MPC Exchange the FRU group 11. Record
the following action for use if the
problem is not corrected by the FRU
exchange; A MOSS microcode
problem is suspected. Call your
support structure, refer to “Contacting
Support” on page A-1.
AB3ñMoss level 0 error detection; Register Storage; PIO
Storage ECC; Data parity whilst accessing MSC
AB4ñMoss level 0 error detection; Register Storage; PIO
Storage ECC; Unresolved problem
AB5ñMoss level 0 error detection; Register Storage; Storage
ECC; Check during PSV swap
AB6ñMoss level 0 error detection; Memory Storage; CHIO
Storage ECC; Data parity Exchange the FRU group 11. Record
the following action for use if the
problem is not corrected by the FRU
exchange; A MOSS microcode
problem is suspected. Call your
support structure, refer to “Contacting
Support” on page A-1.
AB7ñMoss level 0 error detection; Memory Storage; Storage
ECC; Data parity ( NOT ON level 2)
AB8ñMoss level 0 error detection; Memory Storage; Storage
ECC; Instruction fetch parity
1-30 3745 Models 130 to 17A: MIP
