3745 Panel Codes

Table 1-5 (Page 31 of 33). Panel Codes. An

ñ
following a panel code denotes that the code should 'Blink'.
Panel
Code Definition Action: Go to “3745 FRU Group
Table” on page 1-49
or to MAP number
FE1 Errors detected during IML sequence; disk initialization
failure A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14. Be aware that the
IBM
3745 Service Functions, Chapter 11
may be used later during the investi-
gation.
FE2 Errors detected during IML sequence; disk load opera-
tion failure
FE3 Errors detected during IML sequence; power error A -
get end of IML data
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14.
FE4 Unused Go to “MAP 3220: Undefined Panel
Message” on page 2-5
FE5 Errors detected during IML sequence; panel error
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14. Record “How to Run the
Control Panel Test” on page 3-8
which may assist problem isolation.
FE6 Errors detected during IML sequence; MIOC error with
CCU operation
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14.
FE7 Unused Go to “MAP 3220: Undefined Panel
Message” on page 2-5
FE8 Errors detected during IML sequence; disk error when
reading CDF
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14. Be aware that the
IBM
3745 Service Functions, Chapter 11
may be used later during the investi-
gation.
FE9 Errors detected during IML sequence; CDF not created A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14. Be aware that the

IBM

3745 Service Function Chapter 9 and

11

may be used later during the
investigation.
FEA Errors detected during IML sequence; CDF access
function(s) error
FEB Errors detected during IML sequence; NCP time out on
mailbox to CCU A
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14. Record whether this code
can be resolved by use of the
Problem Determination Guide
,
SA33-0096. Perform a MOSS IML but
if problem occurs again Contact
your support structure.
FEC to
FED Unused Go to “MAP 3220: Undefined Panel
Message” on page 2-5
FEE Errors detected during IML sequence; MOSS data
saving error
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14. Record whether this code
can be resolved by use of the
Problem Determination Guide
,
SA33-0096. Perform a MOSS IML but
if problem occurs again Contact
your support structure.
FEF Errors detected during IML sequence; disk error when
reading Port swap file.
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14. Be aware that the
IBM
3745 Service Functions, Chapter 11
may be used later during the investi-
gation.
Chapter 1. START: How to Begin Troubleshooting 1-45
