IBM ibm MAP 5205: LAN Checking

3745/3746-900/Service Processor MAPs

MAP 5205: LAN Checking

You are here because you suspect the LAN cable (WLOB) or the service processor access unit (ACUN) to

be faulty.

001

Perform the following steps:

Check that the service processor LAN cable is correctly connected to the rear of the service processor

and in the service processor access unit.

Check that all the LAN cables are correctly connected to the service processor access unit.

Did you find the problem?

Yes No

002

Exchange the suspected FRU.

003

Problem solved. Go to “CE Leaving Procedure” on page 4-102.

Chapter 2. Map for FRU Isolation 2-41
