3745 Panel Codes

Table 1-5 (Page 30 of 33). Panel Codes. An

ñ
following a panel code denotes that the code should 'Blink'.
Panel
Code Definition Action: Go to “3745 FRU Group
Table” on page 1-49
or to MAP number
F36 to F47 Unused Go to “MAP 3220: Undefined Panel
Message” on page 2-5
F48 Errors detected during the IPL sequence; CCU and
CACHE checkout failed SCTL checkout failed
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14.
F49 Unused Go to “MAP 3220: Undefined Panel
Message” on page 2-5
F4A Errors detected during the IPL sequence; SCTL initial-
ization failed
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14.
F4B Errors detected during the IPL sequence; switch
checkout failed
F4C Errors detected during the IPL sequence; permanent
level 1 in CCU, no need to load CLDP
F4D Errors detected during the IPL sequence; channel moni-
toring failure in normal monitor mode, during FB or SB
F4E Errors detected during the IPL sequence; reset
adapters can not be performed during FB or SB
F4F Errors detected during the IPL sequence; problem
detected by the CDF
F50 Errors detected during the IPL sequence; CP not set
ONLINE by the fallback or switchback
F51 Errors detected during the IPL sequence; bus switching
operation unsuccessful
F52 Errors detected during the IPL sequence; problem
detected with the MCAD interface
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14.
F53 Error detected during the IPL sequence; fallback func-
tion not supported
F54 Errors detected during the IPL sequence; no buffer
available for NCP during fallback
F55 Errors detected during the IPL sequence; NCP / MOSS
fallback interface error
F56 Errors detected during the IPL sequence; interface
problem between fallback-switchback and channel mon-
itoring
F57 Errors detected during the IPL sequence; CCU power
has dropped during the IPL
A reference code will have been
produced on the 3745 console. Refer
to “Using Reference Codes” on
page 1-14.
F58 Errors detected during the IPL sequence; error during
SBK protocol
F59 Error detected during MOSS IML diagnostics; IPL can
not be performed on the selected CCU
F5A Errors detected during the IPL sequence; CA configura-
tion from CDF does not match the actual configuration
F60 Error detected during MOSS IML Diagnostics; IPL can
not be performed on CCU
F61 IPL cancelled after IPL abort
F62 Error detected during MOSS IML Diagnostics; IPL can-
celled after a stop in phase 1 diagnostic
F63 to FD5 Unused Go to “MAP 3220: Undefined Panel
Message” on page 2-5
FD6 Status/progression step which occurs during the IPL
sequence; the control program loading is started from
the Disk
If this code is displayed for more than
2 minutes, when the load/dump is via
the disk, then refer to “How to Run
MOSS Diagnostics” on page 3-4 to
aid problem isolation and refer to
IBM

3745 Service Functions

, "Hard Disk
Trouble Analysis".
FD7 Status/progression step; dump control program on
MOSS disk in progress
FD8 Status / Progression step; save control program on
MOSS disk in progress
FD9 to FE0 Unused Go to “MAP 3220: Undefined Panel
Message” on page 2-5
