LIC Board Type 2 Packaging for LIC Type 6 (Low Speed)
S
M
U
X
A
LIC Locations
in Board 01L-A2
ABCDEFGHJK
33 34 35 36 37 38 39 40
S
M
U
X
A
Line Locations
in Board 01L-A2
ABCDEFGHJK
64 66 68 70 72 74 76 78
Figure 4-19. 3745 LIC Board 01L-A2 Packaging (LICs Type 6 Low Speed)
S
M
U
X
A
LIC Locations
in Board 01L-A1
ABCDEFGHJK
41 42 43 44 45 46 47 48
S
M
U
X
A
Line Locations
in Board 01L-A1
ABCDEFGHJK
80 82 84 86 88 90 92 94
Figure 4-20. 3745 LIC Board 01L-A1 Packaging (LICs Type 6 Low Speed)
