IBM ibm 3745 Control Panel Code

3745 MAPs

3745 Control Panel Code

Notes:

1. Use the

Token-Ring Network Problem Determination Guide

, SX27-3710.

2. Check the ring and the service processor. Go to the

Service Processor Installation and Maintenance

manual, chapter "Service Processor Problem Determination".

Table 2-2. 3745 Control Panel Code

3745 Control

Panel Code Description Action

B8F LAN adapter check Exchange the MLA card.

B90 Hardware init error Suspect a hardware problem (see Note 1).

B91 Microcode error Contact your support structure for assistance.

B92 Lobe media test failure Suspect a hardware problem (see Note 1).

B93 Signal loss while opening Suspect a ring problem (see Note 1).

B94 Wire fault while opening Suspect a hardware problem (see Note 1).

B95 Open frequency error Suspect a ring problem (see Note 1).

B96 Time out while opening

B97 Ring failure while opening

B98 Ring beaconing while open

B99 Duplicate node address

B9A Open request parameters

B9B Open remove received

B9C Open IMPL force received

B9D No monitor for RPL at open

B9E Lobe wire fault at open Suspect a hardware problem (see Note 1).

B9F Remote station connected

Time out Suspect a problem in the service processor

or ring problem (see Note 2).

BB0 Link lost

BB1 DM/DISC received /acked

BB2 FRMR received

BB3 SABME received

BB4 Ti Timer expired

BB5 FMMR sent

BB6 Unexpected SABME received

BC0 Permanent ring beaconing Suspect a ring problem (see Note 1).

BC1 Lobe wire fault Suspect a hardware problem (see Note 1).

BC2 Auto-removal while

beaconing

BC3 Remove received Suspect ring problem (see Note 1)

BC4 Auto-removal Suspect a hardware problem (see Note 1).

BD0 FSM time out Suspect a problem in the service processor.

(see Note 2)

BE0 Watchdog time out

2-32 3745 Models 130 to 17A: MIP
