To configure the DVR to work with DDNS:

1)Press Menu and Select Login / Logout

2)Type in the username and password. (default username is “aa”. Default password is “11”

3)Select Setup

4)Select Network

5)Change the Net Type to static. Note that the DHCP IP information should be copied over to Static.

6)Navigate to DDNS and press - / + to choose the DDNS website you have created. Our instructions were for DynDNS.org.

The following information will be acquired from the DDNS account you have set up online.

7)Enter the hostname of your DDNS account. (ex BriansDVR.dyndns.org)

8)Enter the username of the account you created

9)Enter the password of the account you created

The DVR will now automatically log on to your DDNS account and update the website with your current External IP Address.

IF YOU CANNOT CONNECT USING YOUR EXTERNAL IP ADDRESS

If the Remote Viewing Software does NOT pop up, it could be that:

•Make sure you are using Internet Explorer 6.0 or later.

•Port forwarding is not set up.

•You are not an administrator on the computer and cannot install the Microsoft add-on program.

•A pop-up blocker is preventing the controls or DVR from showing up.

•Your router is blocking your computer from using the External IP Address. Try connecting to this address from a remote computer that is not on the same network.

•A DSL modem is preventing a connection.

•Port 80 is being blocked by your ISP (Internet Service Provider). Try changing the HTTP port to 2000. Port forwarding will need to be set up for this port also.

Check all your network connections and go through the above steps again to make sure a configuration error was not made. You may have to configure PPPoE settings to match the settings provided to you by your Internet Service Provider (ISP). Consult your ISP for more information on your PPPoE settings.

If using a http port other then 80 the IP address must be entered with the port number at the end. (ex. http://74.11.213.177:2000 or http://74.11.213.177 :2000) some Internet Explorer browesers require a space before the port number.
