Operation

Blodgett IQ2T Control

PROGRAMMING MULTIPLE STAGE RECIPES Entering the Programming Mode:

1.Press and hold the PROG KEY (10). The top display reads CodE.

2.Use the product keys to enter the program- ming access code: 3 1 2 4. Press the ENTER KEY (14). The top display reads Prod.

3.Press the desired product key followed by the ENTER KEY (14).

Programming the Cook Time:

NOTE: When multiple stage cooking is being used, the countdown time displayed dur- ing cooking is the sum of all stages.

1.The top display reads P1:__. The bottom dis- play gives the current programmed cook time for stage 1 in minutes:seconds. Press the TOGGLE/CLEAR KEY (11). Use the product keys to enter the new cook time. Press the EN- TER KEY (14) to save the new cook time.

2.The top display reads P2:__. The control is asking for the cook time for the second stage of this recipe. Repeat Step 1 for each addition- al stage.

3.When the cook times for all stages are pro- grammed, press the TOGGLE/CLEAR KEY (11) to clear the bottom display.

NOTE: This tells the controller that there are no more stages for this recipe. Once the number of stages has been estab- lished the control will only allow en- tries for these stages on all further pa- rameters for this product.

4.Press the ENTER KEY (14) again. The display reads P1:. The bottom display shows the cook time.

5.Press the SCAN KEY (15) to advance the pro- gramming mode to cook temperature.

Programming the Cook Temperature:

1.The top display reads Ct ---1. The bottom dis- play gives the current cook temperature for stage 1 of this recipe. Use the product keys to enter the desired cook temperature.

2.Press the ENTER KEY (14) to save the new cook temperature for stage 1. The top display reads Ct---2.

NOTE: Repeat Steps 1 ---2 to program the cook temperature for additional stages. When the cook temperature for the final stage has been entered the top display reads Ct ---1.

3.Press the SCAN KEY (15) to advance the pro- gramming mode to fan speed

Programming the Fan Speed:

1.The top display reads SPd1. The bottom dis- play gives the current fan speed. Press the TOGGLE/CLEAR KEY (11). The bottom dis- play toggles between HI and Lo.

2.Press the SCAN KEY (15) to advance the pro- gramming mode to the fan cycle time.

28
