Configuring the ISDN LAN Modem from a Remote Location 75
7Right click this new icon with your right mouse button and choose Properties.
8Click the Server Type tab.
For Windows 95 users: PPP, Windows 95, Windows NT 3.5, Internet should be chosen in the Type of
For Windows 98 users: PPP, Internet, Windows NT Server, Windows 98, should be chosen in the Type of
9Under Advanced Options, uncheck all boxes.
10Choose the TCP/IP check box for Allowed Network Protocols. Uncheck the boxes for NetBEUI and IPX/SPX Compatible.
11Click TCP/IP Settings.
The TCP/IP Settings window opens.
12Click Specify an IP address and enter an IP address for your computer. Enter 192.168.2.1 if you are not sure.
13Leave the other options for this window at their default settings, including the radio button for Server assigned name server addresses.
14Click OK to close the TCP/IP Settings window.
15Click OK to close the Server Types window.
16Click OK to close your connection window.
17
The Connect To window will open. You may choose to leave the Username and Password fields blank at this time.
18Click Connect.
Your local computer will dial and establish a connection with your remote ISDN LAN Modem.
19Once your call has been established, launch a Web browser on your local computer.
The Web browser attempts to load its default Start Page. Click Stop to cancel this procedure.
20Enter the following address in your Web browser’s address bar: http://192.168.1.1/ to go to the remote ISDN LAN Modem’s main configuration page.
If you previously set your ISDN LAN Modem’s IP address to something other than the factory default address, enter this IP address in your Web browser’s address bar in place of the address shown in the URL above.
21Enter your password if required and then click Submit.
The ISDN LAN Modem main configuration page appears. You now have full access and can make any configuration changes as if you were connected via your local LAN. Note that you are limited to configuration of the LAN Modem when dialing in from a remote location. For instance, you cannot access the Web when during a remote dial in session.
