[Description] Selects a bar code system and prints the bar code. m selects a bar code system as follows:
m |
| Bar Code System | Number of Characters | Remarks |
|
| |||||
① | 0 |
| 11 ≤ | k ≤ | 12 |
| 48 ≤ | d ≤ | 57 |
|
|
| 1 | 11 ≤ | k ≤ | 12 |
| 48 ≤ | d ≤ | 57 |
|
| |
| 2 | JAN13 (EAN13) | 12 ≤ | k ≤ | 13 |
| 48 ≤ | d ≤ | 57 |
|
|
| 3 | JAN 8 (EAN8) | 7 ≤ | k ≤ 8 |
| 48 ≤ | d ≤ | 57 |
|
| |
| 4 | CODE39 | 1 ≤ | k |
|
| 48 ≤ | d ≤ | 57, 65 ≤ | d ≤ | 90, 32, 36, 37, |
|
|
|
|
|
|
| 43, 45, 46, 47 |
|
| ||
| 5 | ITF | 1 ≤ | k (even number) | 48 ≤ | d ≤ | 57 |
|
| ||
| 6 | CODABAR | 1 ≤ | k |
|
| 48 ≤ | d ≤ | 57, 65 ≤ | d ≤ | 68 , 36, 43, 45, |
|
|
|
|
|
|
| 46, 47, 58 |
|
| ||
② | 65 | 11 ≤ | n ≤ | 12 |
| 48 ≤ | d ≤ | 57 |
|
| |
| 66 | 11 ≤ | n ≤ | 12 |
| 48 ≤ | d ≤ | 57 |
|
| |
| 67 | JAN13 (EAN13) | 12 ≤ | n ≤ | 13 |
| 48 ≤ | d ≤ | 57 |
|
|
| 68 | JAN 8 (EAN8) | 7 ≤ | n ≤ | 8 |
| 48 ≤ | d ≤ | 57 |
|
|
| 69 | CODE39 | 1 ≤ | n ≤ | 255 |
| 48 ≤ | d ≤ | 57, 65 ≤ | d ≤ | 90, 32, 36, 37, |
|
|
|
|
|
|
| 43, 45, 46, 47 |
|
| ||
| 70 | ITF | 1 ≤ | n ≤ | 255 | (even | 48≤ | d ≤ | 57 |
|
|
|
|
| number) |
|
|
|
|
|
| ||
| 71 | CODABAR | 1 ≤ | n ≤ | 255 |
| 48 ≤ | d ≤ | 57, 65 ≤ | d ≤ | 68, 36, 43, 45, |
|
|
|
|
|
|
| 46, 47, 58 |
|
| ||
| 72 | CODE93 | 1 ≤ | n ≤ | 255 |
| 0 ≤ | d ≤ | 127 |
|
|
| 73 | CODE128 | 2 ≤ | n ≤ | 255 |
| 0 ≤ | d ≤ | 127 |
|
|
[Details for ①]
•This command ends with a NUL code.
•When the bar code system used is
•When the bar code system used is JAN13 (EAN13), the printer prints the bar code after receiving 13 bytes bar code data and processes the following data as normal data.
•When the bar code system used is JAN8 (EAN8), the printer prints the bar code after receiving 8 bytes bar code data and processes the following data as normal data.
•The number of data for ITF bar code must be even numbers. When an odd number of data is input, the printer ignores the last received data.
