6.4 Kanji Control Commands

(for Japanese model, Simplified Chinese model, Traditional Chinese model, and Korean model)

FS ! n

[Name]

Set print mode(s) for Kanji characters

[Format]

ASCII

FS

!

n





Hex

1C

21

n





Decimal

28

33

n

[Range]

0

n 255













[Description] Sets the print mode for Kanji characters, using n as follows:



Bit



Off/On

Hex

Decimal

Function



























0





-



-

-



Undefined.



























1





-



-

-



Undefined.



























2





Off



00

0



Double-width mode is OFF.

































On



04

4



Double-width mode is ON.



























3





Off



00

.



Double-height mode is OFF.

































On



08

8



Double-height mode is ON.



























4





-



-

-



Undefined.



























5





-



-

-



Undefined.



























6





-



-

-



Undefined.



























7





Off



00

0



Underline mode is OFF.

































On



80

128



Underline mode is ON.



















[Notes]

When both double-width and double-height modes are set (including right- and left-side







character spacing), quadruple-size characters are printed.





The printer can underline all characters (including right- and left-side character spacing), but







cannot underline the space set by HT and 90° clockwise-rotated characters.





The thickness of the underline is that specified by FS , regardless of the character size.





When some of the characters in a line are double or more height, all the characters on the







line are aligned at the baseline.





It is possible to emphasize the Kanji character using FS W or GS !, the setting of the last







received command is effective.





It is possible to turn under line mode on or off using FS , and the setting of the last received







command is effective.







[Default]

n = 0













[Reference]

FS , FS W, GS !
