ESC \ nL nH

[Name]	Set relative print position
[Format]	ASCII		ESC	\	nL	nH
	Hex		1B	5C	nL	nH
	Decimal		27	92	nL	nH
[Range]	0 ≤	nL ≤	255
	0 ≤	nH ≤	255

[Description] Sets the print starting position based on the current position by using the horizontal or vertical motion unit.

	•	This command sets the distance from the current position to [(nL + nH ⋅ 256) ⋅ horizontal or
		vertical motion unit]
[Details]	•	Any setting that exceeds the printable area is ignored.
	• When pitch N is specified to the right:
		nL+ nH ⋅ 256 = N
		When pitch N is specified to the left (the negative direction), use the complement of 65536.
		When pitch N is specified to the left:
		nL+ nH ⋅ 256 = 65536 - N
	•	The print starting position moves from the current position to [N ⋅ horizontal or vertical motion

unit]

• The horizontal and vertical motion unit are specified by GS P.

• The GS P command can change the horizontal (and vertical) motion unit. However, the value cannot be less than the minimum horizontal movement amount, and it must be in even units of the minimum horizontal movement amount.

• In standard mode, the horizontal motion unit is used.

• In page mode, the horizontal or vertical motion unit differs as follows, depending on the starting point of the printing area:

①When the starting position is set to the upper left or lower right of the printable area using ESC T, the horizontal motion unit (x) is used.

②When the starting position is set to the upper right or lower left of the printable area using ESC T, the vertical motion unit (y) is used.

[Reference] ESC $, GS P
