2) DIP switch 2: 8 switches











Table 3.3.3

DIP Switch 2





SW 2

Function



ON

OFF



1

Handshaking (BUSY condition)



Receive buffer full

Offline











Receive buffer full



2

Reserved (Do not change settings)



---

Fixed to OFF



3

Selects print density /



Refer to Table 3.3.4





4

Low power consumption mode









5

Setting the release condition of the



Releases the BUSY

Releases the BUSY





receive buffer BUSY state (this function

state when the

state when the





is effective when the capacity of the



remaining capacity of

remaining capacity of





receive buffer is set to 4 KB.)



the receive buffer

the receive buffer









reaches 138 bytes.

reaches 256 bytes.



6

Reserved (Do not change settings)



---

Fixed to Off



7

I/F pin 6 reset signal (*1)



Enabled

Disabled



8

IF pin 25 reset signal (*2)



Enabled

Disabled

(*1)(*2) With the RS-485 serial interface specification (a dealer option), DIP Switches 2-7 and 2-8 are disabled.

Table 3.3.4 DIP Switch 2-3 and 2-4

Level

Function

SW 2-3

SW 2-4

Low power consumption mode

ON

ON

1

Print density (Normal)

OFF

OFF

2





ON

OFF















3

Print density (Dark)

OFF

ON

NOTES: Changes in DIP switch settings (excluding switches 2-7 and 2-8 interface reset signals) are recognized only when the printer power is turned on or when the printer is reset by using the interface. If the DIP switch setting is changed after the printer power is turned on, the change does not take effect until the printer is turned on again or is reset.

If you turn on DIP switch 2-7 or 2-8 while the printer power is turned on, the printer may be reset, depending on the signal state. DIP switches should not be changed while the printer power is on.

If the print density is set to level 2 or 3, printing speed is inclined to be low speed.

In low power consumption, printing speed is fixed to 70 mm/s.

TITLE

TM-T88IIIseries

SHEET

NO.

REVISION



EPSON Specification (STANDARD)

B

NEXT

SHEET

54

53









Page 64
Image 64
Epson T88III specifications DIP Switch 2-3
