Changing Your Workstation’s Hardware Configuration
Installing an EISA or GSC Option Board
Graphics Paths
If you are installing a graphics option, read the information in this section first.
graphics0 through graphics2 are not supported. If the configuration value is set to “ default” (graphics 0) , the system console will be graphics 3, Slot 3.
graphics3 Graphics device in slot3. If there is a Dual Graphics Card in slot4, this is the port to the right on the card when facing the back of the worksta- tion.
graphics4 Graphics device in slot4. If there is a Dual Graphics Card in slot 3 or 4, this is the port to the left on the card when facing the back of the workstation.
NOTICE:If you install a
If your model C100/110 is running HPUX 9.05, the system console graphics device must be installed in Slot 3.
If your model C100/110 is running HPUX 9.07 or later, the system will find a console graphics device installed in Slot 3 by default. You may install the console graphics device in Slot 4 if you modify your system files as described in HP Visual User Environment Users Guide or HPUX X User Environment User’s Guide.
148
