NOTICE:

Figure 35

Changing Your Workstation’s Hardware Configuration

Removing the Main Tray Assembly

Removing the Main Tray Assembly

Perform the following steps to remove the Main Tray Assembly:

1Power off the system, the monitor, and any peripheral devices. Unplug the system unit power cord and the power cord of any peripheral devices from ac wall out- lets. Disconnect the power cord from the system unit.

There is no need to manually shut down the HP-UX operating system on your workstation before powering it off. When you turn off the power switch, your workstation automatically shuts down the operating system before terminating the power.

2Disconnect cables from any peripheral devices.

3Attach a static-grounding wrist strap to bare metal on the back panel of the system unit.

4Completely loosen the four captive screws on the rear of the system unit, as shown in Figure 35.

Captive

Screws

Captive Screws

Removing Main Tray Assembly

139
