Hardware Kit

Fasteners

Quantity

(A) Socket head screw, black (⁵⁄₁₆-18 x ¾-inch)

8

(B) Flat washer, black (⁵⁄₁₆ x .688)

12

(C) Buttonhead screw, silver (⁵⁄₁₆-18 x ¾-inch)

6

(D) Flat washer, silver (⁵⁄₁₆ x .688)

6

(E) Buttonhead screw, black zinc (⁵⁄₁₆-18 x ¾-inch)

4

M9.57 Low-Impact Treadmill Assembly Guide

2
