Table 2-3 Fast Ethernet Module LED Descriptions

Chapter 2 Cabling and Troubleshooting the CSS

Cabling the CSS 11503 and CSS 11506 Modules

Table 2-3describes the FEM LEDs and their indications.

Table 2-3 Fast Ethernet Module LED Descriptions

LED Name

Color

State

Indicates









Link

Green

Off

No link established













On

Link established but no activity













Blinking

Link established with transmit or receive







activity









Duplex

Green

Off

Port is operating at half duplex













On

Port is operating at full duplex









Note If all of the FEM Link and Duplex LEDs blink synchronously, the module has failed.

Gigabit Ethernet Module Connectors and LEDs

The Gigabit Ethernet Module (GEM), model CSS5-IOM-2GE, contains two

1000-Mbps SFP GBICs with LC-type connectors. The GEM can use either:

Longwave-length SFP GBICs (CSS5-GBIC-LX). The longwave length transceiver (1000BASE-LX) can reach 550 meters for all multimode media types. For single-mode fiber, the distance is 5,000 meters.

Shortwave-length SFP GBICs (CSS5-GBIC-SX). The transceiver distance can reach from 220 meters to 500 meters, depending on the quality of the fiber.

Warning Because invisible radiation may be emitted from the aperture of the port when no fiber cable is connected, avoid exposure to radiation and do not stare into open apertures.



Cisco 11500 Series Content Services Switch Hardware Installation Guide

2-16

78-13884-06
