Chapter

Power Entry Options

Each power entry module contains its own circuit breaker, which also acts as an ON/OFF switch. The circuit breaker is closed by pressing in the large black button until it latches in the closed position. The circuit breaker is opened by pressing the smaller red button. The DC PEM also includes a bracket that is attached to the PEM to provide cable strain relief. See Chapter 7, “Installation and Start-Up”for details.

AC Powered Systems

In AC-powered systems, a separate AC power assembly is required. (See Figure 2-4and Figure 2-5.) This assembly is rack-mounted under the shelf cooling assembly in the rack and is available in both a single and double AC source line version. The power assembly has a modular design and can be configured with up to six power supply modules, each module providing 875W of 48V DC power. The power assembly can provide power for up to four Cisco MGX 8220 shelves, requiring three power supply modules, or four for a (1 for N) redundant power supply configuration. The rear panel has four connectors which supply 48V DC power to the shelves. The first three (1A, 2A, and 3A) connectors also provide power monitoring information to the Cisco MGX 8220 shelf. Another three connectors (1B, 2B, and 3B) on the rear panel provide monitoring information for the second half of the power supply. Special cables are used from the rear of the power assembly to the rear of the shelves to feed power and monitor data to the shelves.

The AC power assembly measures

•5.25 inches (3 mounting units) high

•17.45 inches wide

•23 inches deep

Figure 2-4 AC Power Assembly (front without grill)

H8246

Figure 2-5 AC Power Assembly (rear)

Power and

monitor cables to MGX 8220 shelf



















































































































































































































































































3B 2B 1B









4A 3A 2A 1A









Monitor connectors







Power connectors































& monitor



Optional

Primary AC



secondary



source



AC source

























H8247





Cisco MGX 8220 Installation and Configuration















Release 5.0, Part Number 78-6430-03 Rev. D0, November 2003





2-5
