Windows - FastManage Configuration Utilities

3.6.1TCP/IP Configuration

You make a series of choices to conÞgure the NIC on TCP/IP networks. Below is a hierarchy of these choices.

From TCP/IP ConÞde., selections include:

IP ConÞguration -->

¥IP Address: Allows you to change the IP address of the device. Changes take effect at system reset. Exit and relaunch the utility.

¥Subnet Mask: Sets the subnet mask address for the device.

¥Gateway Address: Sets up the address of the router that routes IP packets across subnets.

¥Enable RARP: When enabled, the device will try to obtain its IP address using RARP at power-up.

¥Enable BOOTP: When enabled, the device tries to obtain its IP address using BOOTP at power-up.

¥IP Traps -->

¥Enable IP Traps: When enabled, sends ÒtrapsÓ (problems) to a designated system.

¥IP Traps Hosts: Designates where the traps will be sent.

¥Enable DHCP: Enables/disables the DHCP feature.

LPD ConÞguration: Enables BSD-type LPD print services and its options.

3-22 July 1998
