DS62-Network, DS62-MD4 Network/Modem Host Module

DS62 usernames as backup login is Disabled

Enable ? (Y/N), CR for no change) :

Select “TACACS Encryption Enable” to turn TACACS+ encryption off or on. Sending unencrypted TACACS packets is useful for troubleshooting but should not be used under normal operations.

TACACS

encryption is

Enabled

Enable

? (Y/N), CR for no change) :

Select “TACACS Server Port to assign a more secure port, default is TCP 49.

TACACS server port is: 49

Enter port number (>= 1024, D for default 49): 12

If you type a port number less than 1024 the Host Module responds with the following until a valid entry is typed:

TACACS server port is: 49

Enter port number (>= 1024, D for default 49): 1234

Network Port Configuration

This menu is used to change the network configuration options such as the IP Address, Subnet Mask, Gateway, DHCP, and Telnet; all of which are necessary during initial startup. The Connection Inactivity Timeout allows you to enable/disable whether the firmware will end your session or “times out.” The default is 1 hour, but when disabled there is no set time out. Disabling the Carriage Return Translation allows you to bypass all unnecessary carriage returns, and it will send you straight to the next “end of line.” The DHCP, Telnet, SSH, options is to enable or disable these functions. SSH host key Generator allows the user to generate a host key which is used in the SSH encryption process. IP Filter allows or blocks specific IP Addresses, SNMP provides a message format for communication between a computer and your devices, and Web Server Configuration allows web access and sets up options for each.

27
