Signal Definitions

32580B

3.4.2Memory Interface Signals (Continued)

Signal Name

Ball No.

Type

Description

Mux











SDCLK_IN

AJ27

I

SDRAM Clock Input. The SC2200 samples the memory

---







read data on this clock. Works in conjunction with the









SDCLK_OUT signal.













SDCLK_OUT

AK28

O

SDRAM Clock Output. This output is routed back to

---







SDCLK_IN. The board designer should vary the length of









the board trace to control skew between SDCLK_IN and









SDCLK.













3.4.3Video Port Interface Signals

Signal Name

Ball No.

Type

Description

Mux











VPD7

G31

I

Video Port Data. The data is input from the CCIR-656

---







video decoder.



VPD6

H28



---















VPD5

H29





---











VPD4

H30





---











VPD3

H31





---











VPD2

J28





---











VPD1

J29





---











VPD0

J30





---











VPCKIN

F31

I

Video Port Clock Input. The clock input from the video

---







decoder.













AMD Geode™ SC2200 Processor Data Book

55
