96 AMD Geode™ SC2200 Processor Data Book
SuperI/O Module
32580B
5.1 Features
PC98 and ACPI Compliant
•PnP Configuration Register structure
•Flexible resource allocation for all logical devices:
— Relocatable base address
— 9 parallel IRQ routing options
— 3 optional 8-bit DMA channels (where applicable)
Parallel Port
•Software or hardware control
•Enhanced Parallel Port (EPP) compatible with version
EPP 1.9 and IEEE 1284 compliant
•EPP support for version EPP 1.7 of the Xircom specifi-
cation
•EPP support as mode 4 of the Extended Capabilities
Port (E CP)
•IEEE 1284 compliant ECP, including level 2
•Selection of internal pull-up or pull-down resistor for
Paper End (PE) pin
•PCI bus utilization reduction by supporting a demand
DMA mode mechanism and a DMA fairness mechanism
•Protection circuit that prevents damage to the Parallel
Port when a printer connected to it powers up or is oper-
ated at high voltages, even if the device is in power-
down
•Output buffers that can sink and source 14 mA
Serial Port 1
•16550A compatible (SIN1, SOUT1, DTR1#/BOUT1
signals only)
Serial Port 2
•16550A compatible
Serial Port 3 / Infrared (IR) Communication Port
•Serial Port 3
— SIN and SOUT signals only
— Data rate of up to 1.5 Mbps
— Software compatible with the 16550A and the 16450
— Shadow register support for write-only bit monitoring
— DMA support
•IR Communication Port
— IrDA 1.1 and 1.0 compatible
— Data rate of up to 115.2 Kbps (HP-SIR)
— Data rate of 1.152 Mbps (MIR)
— Data rate of 4.0 Mbps (FIR)
— Selectable internal or external modulation/demodula-
tion (ASK-IR and DASK-IR options of SHARP-IR)
— Consumer-IR (TV-Remote) mode
— Consumer Remote Control supports RC-5, RC-6,
NEC, RCA and RECS 80
— DMA support
System Wakeup Control (SWC)
•Power-up request upon detection of RI2#, CEIR, or
SDATA_IN2 activity:
— Optional routing of power-up request on IRQ line
•Pre-programmed CEIR address in a pre-selected
standard (any NEC, RCA or RC-5)
•Powered by VSB
•Battery-backed wakeup setup
•Power-fail recovery support
Real-Time Clock
•A modifiable address that is referenced by a 16-bit
programmable register
•DS1287, MC146818 and PC87911 compatibility
•242 bytes of battery backed up CMOS RAM in two
banks
•Selective lock mechanisms for the CMOS RAM
•Battery backed up century calendar in days, day of the
week, date of month, months, years and century, with
automatic leap-year adjustment
•Battery backed-up time of day in seconds, minutes and
hours that allows a 12 or 24 hour format and adjust-
ments for daylight savings time
•BCD or binary format for time keeping
•Three different maskable interrupt flags:
— Periodic interrupts - At intervals from 122 msec to
500 msec
— Time-of-Month alarm - At intervals from once per
second to once per month
— Update Ended Interrupt - Once per second upon
completion of update
•Separate battery pin, 3.0V operation that includes an
internal UL protection resistor
•7 µA typical power consumption during power down
•Double-buffer time registers
•Y2K Compliant
Clock Sources
•48 MHz clock input
•On-chip low frequency clock generator for wakeup
•32.768 KHz crystal with an internal frequency multiplier
to generate all required internal frequencies
