Signal Definitions

32580B

3.4.20Power, Ground and No Connections1 (Continued)

Signal Name	Ball No.	Type	Description

AVSSPLL3	AK3	GND	PLL3 Analog Ground Connection.
VPLL2	A17	PWR	3.3V PLL2 Analog Power Connection. Low noise power for PLL2 and
			PLL5.

VPLL3	AJ4	PWR	3.3V PLL3 Analog Power Connection. Low noise power for PLL3,
			PLL4, and PLL6.

AVCCUSB	D27	PWR	3.3V Analog USB Power Connection. Low noise power.
AVSSUSB	C27	GND	Analog USB Ground Connection.
AVCCCRT	A12, C13, D15	PWR	3.3V Analog CRT DAC Power Connections. Low noise power.
AVSSCRT	B14, C14, C15	GND	Analog CRT DAC Ground Connections. Return
			current.

VCCCRT	D12	PWR	1.8V / 2.1V CRT DAC Digital Power Connection. Can be directly con-
			nected to VCORE on PCB (printed circuit board).
VSSCRT	C12	GND	CRT DAC Digital Ground Connection. Can be directly connected to VSS
			on PCB.

VBAT	AL3	PWR	Battery. Provides battery back-up to the RTC and ACPI registers, when
			VSB is lower than the minimum value (see Table 9-3 on page 370). The
			ball is connected to the internal logic through a series resistor for UL pro-
			tection. If battery backup is not desired, connect VBAT to VSS
VSB	AL5	PWR	3.3V Standby Power Supply. Provides power to the Real-Time Clock
			(RTC) and ACPI circuitry while the main power supply is turned off.

VSBL	AL6	PWR	1.8V / 2.1V Standby Power Supply. Provides power to the internal logic
			while the main power supply is turned off. This signal requires a 0.1 μF
			bypass capacitor to VSS. This supply must be present when VSB is
			present.

VCORE	See Table 3-3	PWR	1.8V / 2.1V Core Processor Power Connections.
	on page 41.
	(Total of 28)

VIO	See Table 3-3	PWR	3.3V I/O Power Connections.
	on page 41.
	(Total of 43)

VSS	See Table 3-3	GND	Ground Connections.
	on page 41.
	(Total of 92)

NC	See Table 3-3	---	No Connections. These lines should be left disconnected. Connecting a
	on page 41.		pull-up/-down resistor or to an active signal could cause unexpected
	(Total of 8)		results and possible malfunctions.

1.All power sources except VBAT must be connected, even if the function is not used.

AMD Geode™ SC2200 Processor Data Book

73
