Page 73

9Highlight the driver, and then select to install the updated driver (recommended).

10Click Next.

11Click Next to complete installation.

12Use the default printer name (for example, Dell Laser Printer S2500) or type a unique name for your printer, and then click Next.

13Click Finish to complete the installation.

Using Windows 95 with a parallel cable

NOTE: USB support is not available for Windows 95 operating systems.

When you attached the parallel cable and turned on the printer and computer, the Update Device Driver wizard appeared on your computer screen.

1Insert the Drivers and Utilities CD, and then click Next.

If a system-compatible driver is found on your operating system, the Wizard installs it.

If no compatible system driver is found on your operating system, click Other Locations.

2Browse to the location of the printer driver on the Drivers and Utilities CD, and then click OK.

Use the following table to identify the driver for your language.

If your computer	Select the driver from the list
uses this language
	(Replace the D:\ in the table with the letter of
	your CD-ROM drive)

English	D:\DRIVERS\WIN_9X\ENGLISH\LMPCL5C.INF
French	D:\DRIVERS\WIN_9X\FRENCH\LMPCL5C.INF
German	D:\DRIVERS\WIN_9X\GERMAN\LMPCL5C.INF
Italian	D:\DRIVERS\WIN_9X\ITALIAN\LMPCL5C.INF
Spanish	D:\DRIVERS\WIN_9X\SPANISH\LMPCL5C.INF

Setting up for network printing

73

Image 73
