NioWatch operation

3.Click the OK button.

The calibration and the luminance will be reset to the latest calibrated position.

Note:

When you start up the system, the calibration is also reset to the latest calibrated position. The luminance, however, is kept at the latest value.

To view a graph showing the result of the latest calibration:

1.In the Calibration tab dialog, click on Show calibration chart.

This button is available only if the display has been calibrated with a sensor before.

2.A graph is shown displaying the latest calibration compared to the theoretical display function.

To revert to the default factory settings:

1.In the Calibration tab dialog, click on Reset.

2.As a result, the settings are restored to the default factory values.

Test patterns

Test Patterns

Figure 42: Test Patterns dialog

System manual E1

81
