How to use the on-screen display (OSD)

5.To exit the OSD while saving the changes, select Save & Exit. To exit the OSD without saving the changes, select Cancel.

Note: The OSD disappears automatically after 30 seconds of inactivity.

Main Menu
-(Down)	+(Up)
Brightness	35
		-> Highlighted bar
Contrast	50
Auto Adjust *
H Position *	75
V Position *	29
Color *	>
Clock	>
Languages	>
Input	>
Lock Controls	>
Cancel
Save & Exit
		-> Input type & video format
A1 1024x768 - 60.1	48.4k

Figure 47

Note: The functions indicated with an * are not available when the DVI (digital) input is selected.

The highlighted bar indicates the status of the mode:

•A steady highlighted bar indicates the function is selected and ready to be adjusted.

•A blinking highlighted bar indicates OSD is in parameter adjusting mode.

88 System manual E1
