Chapter 3 : Creating a Project

Extract To

Set the ending position if extracting only certain



characters from the input



For example, if you set Extract From 4 and



Extract To 6, you will extract “555” out of



0005550

Force Uppercase

Force Uppercase input. Users will not be able to



enter lower case letters into a screen prompt if



this option is selected

Default Value

Type a value or set a default value using the



contents of a variable. If you use a variable,



remember to assign a value to the variable



someplace in your label program

Result Value

Select the variable in which the user input



should be stored

Output Format

Set the format you want to use when saving the



input from the external keyboard. Several



options are available such as fill blank on left,



fill zeros on left. Select the appropriate format



for your program design.
