Chapter 3 : Creating a Project

3.3.2.6. Select Value from File

General introduction

As discussed in Section 3.3.2 – Variables, Input Methods, several input



methods are available for your screen prompts.



This section discusses the Select Value from File input method and the



properties you need to set up when you select this input type.





Select Value From File allows the user to select the input from a predefined lookup file (please reference Section 3.4 – Lookup Files).

For Select Value From File the property settings are as follows:

Local File Name

Select the file to be used to lookup the



desired input. Files are available for



selection here only once they have



been added to your label program as



Lookup Files

Select Record Using Field

Select the field in your file which you



want to use as your browse or search



field.

Start Browse With

Indicate from which point in the file



you want to begin your browse.

Keyboard Input to

Check this checkbox to allow the user

Search Data (F1)

to enter, via an external keyboard, the



item for which they want to search in



the file. The user first presses the F1



key to enable the keyboard entry.

Copy Value to Variable

Select the variable(s) in which the user



input should be stored
