Tips:

To view additional information for any screen, tap the Help icon ( ).

To modify your connection settings, tap Manage existing connections on the Connections screen, and complete the connection wizard.

Work Network Connections

A Virtual Private Network (VPN) connection allows you to access your company network through your device’s Internet connection, whereas a proxy connection lets you access the Internet using an existing connection to your corporate or WAP network.

To connect to a private network:

1.Obtain the following information from your network administrator:

Server phone number.

User name and password.

Domain (provided by the network administrator).

2.Tap Start > Settings > Connections tab > Connections.

3.In My Work Network, follow the instructions for each type of connection.

4.Complete the connection wizard, and then tap Finish.

Starting a Data Connection

After a data connection has been set up on your device, you can then connect your device to the Internet. The connection is started automatically when you begin using a program that requires an Internet connection. For example, when you start Internet Explorer Mobile to browse the Internet, your device connects automatically.

To manually start a data connection:

1.Tap Start > Settings > Connections tab > Connections.

2.Tap Manage existing connections.

3.Tap and hold the name of the desired connection, and then tap Connect.

To disconnect a data connection:

On the Comm Manager screen, tap the Data Connection button ( ).

128 Section 11: Getting Connected
