Page 168

A.1 Speciﬁcations

System Information

Processor	QUALCOMM® MSM7500, 400 MHz
Memory	ROM : 256 MB embedded NAND Flash
	RAM : 64 MB SDRAM
	(Figures are the total ROM and RAM memory available for use and storage. Since the memory is
	shared by the Operating System, applications, and data, the actual available memory is less than
	what is written.)
Operating System	Windows Mobile® 6.1 Professional

Power

Battery	Rechargeable Lithium-Ion polymer battery, 1500 mAh
Charging Time	Under 4 hours
AC Phone Charger	Voltage range/frequency: 100 - 240V AC, 50/60 Hz
	DC output: 5V and 1A

Display

LCD Type	2.8” transmissive TFT-LCD with backlight LEDs, touch-sensitive screen
Resolution	240 x 320 dot pixels with 64K colors
Alignment	Portrait and Landscape

Cellular Radio Module

Functionality	CDMA2000 1xEVDO/1xRTT and IS-95A/B voice or data
Mode	Dual-band (800 and 1900 MHz)
Internal Antenna	Yes

Physical

Dimensions	4.3” (L) x 2.3” (W) x 0.7” (T)
Weight	6.5oz (with battery)

Camera Module

Type	2 Megapixel color CMOS camera with flash
Resolution	Photo: 1600x1200 (UXGA), 1280x960 (SXGA), 640x480 (VGA), 320x240 (QVGA), 160x120 (QQVGA)
	Video: 352x288 (CIF), 320x240 (QVGA), 176x144 (QCIF), 128x96
Digital Zoom	Up to 8x

172 Appendix

Image 168
