Page 137

Supported File Formats

The camera in your device captures ﬁles in the following formats:

Capture type	Format

Still image	JPEG

Video	MPEG-4 (.mp4)
	Motion-JPEG (.avi)
	H.263 (.3gp)
	3GP2 (.3g2)

Panorama / Sports / Burst	JPEG

Camera Controls

Use the following device buttons and onscreen controls to take photos or video clips and to modify settings.

The Camera Key, ENTER button, and Jog Wheel

The Camera Key, ENTER button, and Jog Wheel can all be used as the shutter release.

Press to take a photo or to take shots for a picture theme or panorama.

Press to start recording video; press again to stop recording.

To take consecutive shots in Sports mode, press the Camera Key brieﬂy, and then move your device to follow the movement of your subject.

Press and hold when taking consecutive shots in Burst mode.

The Navigation Control

Press the Navigation Control up or down to increase or decrease the zoom level.

Press the Navigation Control left or right to go to the previous or next sequential capture mode.

Onscreen controls and indicators

1

2

3

4

5

6

7

8

9 10 11 12

Photo mode

1Mode Switching control. Tapping the left/right arrow ( capture mode.

2Resolution. The resolution icon ( / / / / toggle between different resolutions.

/ ) on the screen allows you to switch the

) indicates the current resolution. Tap to

Section 12: Experiencing Multimedia

139
