serial devices through two buffered 16C550 UART serial ports, supporting up to 115.2 KB per second

two USB devices

joystick through the MIDI/game port

speaker and microphone connectors (line in, line out, microphone in).

The following table lists the major components on the system board.

System Board Components

Component

Function

Pentium III Processor

667-MHz or higher processor , 133-MHz or higher FSB

Intel 820 Chipset:



82820 Memory Controller Hub

Uses Intel graphics technology, software drivers, and

(MCH)

Direct AGP (integrated AGP) to create vivid 2D and 3D



effects and images. Features integrated Hardware Motion



Compensation to improve video quality.



Features processor and host bus optimized for the



processor, integrated RDRAM controller, 3D graphics



visual enhancements, 3D graphics texturing



enhancements, digital video output, integrated 24-bit



230 MHz RAMDAC, 2D graphics, arithmetic stretch blitter



video, integrated graphics memory controller, display



cache interface, arbitration scheme and concurrency, data



buffering, power management functions, and support for



I/O bridge.

82801AA I/O Controller Hub

Uses Accelerated Hub Architecture to make direct

(ICH)

connection from graphics and memory to the integrated



AC97 controller, IDE controller, and dual USB ports.



Supports PCI bus interface, integrated IDE controller,



USB, AC’97 Link for audio and telephone Codecs,



interrupt controller, timers, 3.3V operation, power



management logic, enhanced DMA controller, real-time



clock, SM bus, and Firmware Hub.

82802 Firmware Hub (FWH)

Stores system BIOS and video BIOS, eliminating a



redundant nonvolatile memory component. In addition, the



82802 contains a hardware Random Number Generator



(RNG). The Intel RNG provides truly random numbers to



enable fundamental security building blocks supporting



stronger encryption, digital signing, and security protocols.



Features Intel Platform Compatibility, Firmware Hub



Hardware Interface Mode, configurable interfaces, flash



memory for non-volatile storage, and address/address



multiplexed interface mode.





4-8 System Board
