GS ( k QR Code<Function 165>

VERSAJET MP3200

Command Descriptions

GS ( k QR Code<Function 165>

Programming Reference

[Format]	ASCII		GS ( k pL pH cn fn n1 n2
	Hex		1D 28 6B 04 00 31 41 n1 n2
	Decimal		29 40 107 04 00 49 65 n1 n2
[Range]	(pL + pH x256) = 4 (pL = 4, pH = 0)
	cn = 49, fn = 65
	n1	= 49, 50, 51
	n2	= 0
[Default]	n1	= 50, n2 = 0
[Description]	Specifies the model of QR Code.

		n1	Function

49Specifies model 1.

50Specifies model 1.

51Micro QR

[Notes]

Settings of this function affect the processing of Functions 181 and 182.

Settings of this function are effective until ESC @ is executed, the printer is reset, or the power is turned off.

126	Preliminary Rev. 02

Image 132
