Page 141

Size and Type

Command Descriptions

VERSAJET MP3200

Programming Reference

[Data Format]

Item

ANSI message header

Transportation Data Format Header

Ship-To Postal Code

Ship-To Country Code

Class of Service

Tracking Number

UPS Standard Carrier Alpha Code

UPS Shipper Number

Julian Day of Pickup

Shipment ID Number

Package In Shipment (package N of

X total packages)

Weight in pounds

Address Validation

Ship-To Address

Ship-To City

Ship-To State

End of format

End of transmission

Size and Type

[ ]> <RS>

01 <GS> 96

5 or 9 digits in the USA (mode2), up to 6 alphanumeric characters in other countries (mode3).

3 digits (840 for USA)

3 digits

10-character alphanumeric “UPSN”

6-character alphanumeric

3 digits

1-30 character alphanumeric

1-4 digits “/” 1-4 digits

1-5 digits “Y” or “N”

1-35 alphanumeric

1-35 alphanumeric

2-character alpha <RS>

<EOT>

135	Preliminary Rev. 02

Image 141
