VERSAJET MP3200

Programming Reference

Command Descriptions

For ITF (Interleaved 2 of 5) (m = 5, 70) process

‹Start code and stop code are added automatically.

‹Check digits are not calculated and added.

For CODEBAR (NW-7) (m = 6, 71) process

‹Start code and stop code are not added automatically. Transmit data including the codes.

„Specify the start code (ASCII = “A“ ~ “D,” / Hex = 41H ~ 44H, / Decimal = 65 ~ 68) at beginning of the data (d1).

„Specify the stop code (ASCII = “A“ ~ “D,” / Hex = 41H ~ 44H, / Decimal = 65 ~ 68) at end of the data (dk or dn).

„Start code or stop code (ASCII = “A“ ~ “D,” / Hex = 41H ~ 44H, / Decimal = 65 ~ 68) cannot be specified in bar code data.

‹Check digits are not calculated and added.

For CODE93 (m = 72) process

‹Start code and stop code are added automatically.

‹Check digits (2 character) are calculated and added automatically.

‹Special character HRI is processed as follows:

„The printer prints an HRI character " " as start and stop character.

„The printer prints HRI characters " + an alphabetic character" as a control character (unprinted character).

168

Preliminary Rev. 02
