Command Descriptions
VERSAJET MP3200
Programming Reference | | In CODE B, following data can be used. |
|
| |||
|
|
| |||||
|
| Character data: It is specified by ASCII code [in hexadecimal: 20H ~ 7FH / in decimal: | |||||
|
| 32~127] when specify "{", transmit “{{“ as 2 byte data (It is described separately). | |||||
|
| Special character data: (FNC 1, FNC 2, FNC 3, FNC 4, SHIFT, CODE A, CODE C): It | |||||
|
| is specified “{+ character code" as 2 byte.(It is described separately). | |||||
| In CODE C, following data can be used. |
|
| ||||
|
| Numerical data: It is specified each 2 digit as 1 byte by ASCII code | |||||
|
| [in hexadecimal: 00H ~ 63H / in decimal: 0~99] | |||||
|
| Example: When specify "012345", specify [in hexadecimal: 01H, 17H, 2DH / in | |||||
|
| decimal: 1, 23, 45] as 3 byte. |
|
| |||
|
| Special character data: (FNC 1, CODE A, CODE B) : It is specified “{+ character code" | |||||
|
| as 2 byte (It is described separately). |
|
| |||
| Special characters are defined by combining two characters "{+ an alphanumeric | ||||||
|
| character." The ASCII character "{" is defined by transmitting "{" twice consecutively. | |||||
|
|
|
|
|
|
|
|
|
| Specific Character |
| Transmit data | |||
|
| ASCII |
| Hex | Decimal |
| |
|
|
|
|
| |||
|
| SHIFT | {S |
| 7B, 53 | 123, 83 |
|
|
| CODE A | {A |
| 7B, 41 | 123, 65 |
|
|
| CODE B | {B |
| 7B, 42 | 123, 66 |
|
|
| CODE C | {C |
| 7B, 43 | 123, 67 |
|
|
| FNC1 | {1 |
| 7B, 31 | 123, 49 |
|
|
| FNC2 | {2 |
| 7B, 32 | 123, 50 |
|
|
| FNC3 | {3 |
| 7B, 33 | 123, 51 |
|
|
| FNC4 | {4 |
| 7B, 34 | 123, 52 |
|
|
| { | {{ |
| 7B, 7B | 123, 123 |
|
170 | Preliminary Rev. 02 |
