Page 175

For CODE128 ( m = 73) process

VERSAJET MP3200

Programming Reference

Command Descriptions

For CODE128 ( m = 73) process

Make sure to specify start character. The start character must be code set selection character (any of CODE A, CODE B, or CODE C) which selects the first code set.

Stop character is added automatically.

In CODE A, following data can be used.

Character data: It is specified by ASCII code [in hexadecimal: 20H ~ 5FH in decimal: 32~95]

Control character data: It is specified by ASCII code [in hexadecimal: 00H ~ 1FH / in

decimal: 0~31]

Special character data: (FNC 1, FNC 2, FNC 3, FNC 4, SHIFT, CODE B, CODE C):It is specified “{+ character code" as 2 byte. (It is described separately.)

169	Preliminary Rev. 02

Image 175
