Command Descriptions

VERSAJET MP3200

Programming Reference	[Notes]	For I and II
		‹ When standard mode is selected, this command is enabled only when the printing
		position is at the head of a line or when no data exists in the print buffer.
		‹ When page mode is selected, this command develops the bar code data in the print buffer
		but the printer does not print the bar code data.
		‹ The bar code width that exceeds the printing area cannot be specified.
		‹ This command feeds as much paper as is required to print the bar code, regardless of the
		line spacing specified by line space setting commands.
		‹ The bar code is not affected by print mode (emphasized, underline, or 90°
		clockwise-rotated), except for upside-down printing mode.
		‹ After bar code printing, the printing position moves to the left end of the printing area. The
		printer enters the status of printing position at the head of a line or no data exists in the
		print buffer.
		‹ The values of m from 0 to 6 in M and from 65 to 71 in N select the same bar code system,
		respectively. The printing results are the same.
		‹ This command specifies m = 0 to 6 and ends with a NUL code.
		‹ When an odd number of data is processed for ITF bar code system (m = 5), the printer
		ignores the last received data.
		‹ The printer processes n bytes from the next data as bar code data by this command
		specifying m = 65 to 71.
		‹ Printing area does not include quiet zone (left/right margin) of bar code. Make sure to
		secure the quiet zone, using this command.

164 Preliminary Rev. 02
