Datamatrix <Function 768>

Command Descriptions

					GS ( k	Datamatrix <Function 768>
		VERSAJET MP3200			GS ( k	Datamatrix <Function 768>


	Programming Reference				[Format]			ASCII	GS ( k pL pH cn fn n
					[Format]			ASCII	GS ( k pL pH cn fn n
								Hex	1D 28 6B 03 00 37 44 n
								Decimal	29 40 107 03 00 55 68 n
					[Range]			(pL + pH x ҏ256) = 3 (pL = 3, pH = 0 )
								cn = 55
								fn = 68
								n = 0 or 1

								n	Bar Code Type

0Datamatrix (standard square shape)

1 Datamatrix ECC200 Rectangle Shape

[Default]	n = 0
[Description]	Specify the Bar Code Type.

[Notes]

n = 0 ,Functions 765 and 766 may be omitted.

Settings of this function affect the processing of Functions 781.

Settings of this function are effective until ESC @ is executed, the printer is reset, or the power is turned off.

[Model-dependent variations]

The setting unit is 1 dot. The width is set in units of 0.125 mm {1/203 inch}.

141	Preliminary Rev. 02

Image 147
