Page 179

GS f

Command Descriptions

					GS f
		VERSAJET MP3200			GS f


	Programming Reference				[Name]	Select font for HRI characters
					[Name]	Select font for HRI characters
					[Format]	ASCII	GS f n
						Hex	1D 66 n
						Decimal	29 102 n
					[Range]	n = 0, 1, 48, 49
					[Default]	n = 0
					[Description]	Selects a font for Human Readable Interpretation (HRI) characters when printing a bar code,
						using n as follows:

nFont of HRI characters

0, 48	Font A
1, 49	Font B

[Notes]

The font set by this command is only effective for HRI characters.

HRI characters are printed at the position specified by GS H.

HRI character is Human Readable Interpretation character indicated with bar code.

173	Preliminary Rev. 02

Image 179
